Reliable and stable long-term operation
Support Modbus Protocol
Tie-down mounting or adhesive mounting
High anti-interference design
for UPS Monitoring/Data Center
SOC SOH Monitoring
+86-18702106858 / +86-21-69156352
ABAT100-C is the string-level sense-and-send node of the ABAT100 family. Clipped on a 35 mm DIN-rail or tie-wrapped to a rack rail, the 90 g module measures bi-directional current (0-1000 A, ±1 %) through an external Hall sensor and simultaneously logs ambient temperature (-5 °C to +105 °C, ±1 °C). A 24 V DC, 1 W supply keeps it alive while its isolated UART port streams Modbus-RTU frames toward the ABAT100-HS collector; address and baud rate are user-selectable, so up to 247 C-units can share the same bus. Over-voltage, short-circuit and ripple-resistant design let it ride unharmed beside high-power UPS or solar inverters. Real-time charge/discharge data feed SOC/SOH algorithms, trigger threshold alarms and enable thermal-runaway early warning without extra hardware. In short, ABAT100-C turns the whole battery string into a transparent, metered circuit.
|
Technical parameters |
Description |
||
|
Working Environment |
Operating temperature: -10℃～50℃ Relative humidity: 5%~95% Atmospheric pressure intensity: 80~110kPa |
||
|
Monitoring Capability |
One C-module monitors the charge and discharge current of a group of batteries against the ambient temperature |
||
|
Monitoring Scope |
2V, 6V, 12V battery pack |
||
|
Measurement range and accuracy |
Measurement content |
Scope |
Accuracy |
|
|
Charging and discharging current |
0~1000A |
±1% |
|
|
Ambient temperature |
-5℃～+105℃ |
±1°C |
|
Power requirements |
DC24V, 1W |
||
|
Protection |
Measurement circuit and power circuit with two levels of protection |
||
|
Communication Interface |
UART port, support MODBUS protocol |
||
|
Insulation withstand voltage |
2000VAC |
||
|
Weight |
90g |
||
