8 Channels Temperature Measurement
Support NTC,PT100/PT1000 ,Thermocouple Sensors
High Accuracy Class 1
5 Channels Alarm output，3 Channels 4-20mA Output
RS485 Communication
+86-18702106858 / +86-21-69156352
ARTM-8L temperature inspection instrument can be connected to NTC, PT 100 / PT1000, thermocouple sensor, 0~5V input. It is mainly suitable for temperature measurement and control of multiple channels, and applied to temperature measurement of low voltage electrical contact, transformer winding, motor winding and other places.
|
Technical Features Function |
Features |
|
|
ARTM-8L |
||
|
Number of measurement channels |
8 |
|
|
Input signal |
Pt100/PT1000/NTC/Thermocouple/0~5V； |
|
|
Measurement Range |
Pt100: Maximum support -99.9℃～600℃, the actual range depends Pt1000: Maximum support -99.9℃～300℃, the actual range |
|
|
Accuracy class (standard signal) |
NTC：±1℃； |
|
|
Auxiliary power |
voltage range |
AC85~265V、DC100~300V， |
|
Power consumption |
≤2W |
|
|
Alarm Output |
Routes |
5 Channels Alarm output |
|
Capacity |
AC250V/5A，DC30V/5A |
|
|
Temperature and humidity input |
1 channel（optional） |
|
|
Transmission Output |
Routes |
3 |
|
Range |
4~20mA |
|
|
Communication |
Protocol |
Modbus-RTU |
|
Interface |
RS485 |
|
|
Baud rate |
1200, 2400, 4800, 9600, 19200 |
|
|
Environment |
TEMP |
Work: -10~+55℃, Storage: -25~+70℃ |
|
HUM |
≤95%, non condensing, non corrosive gas environment |
|
