IEC61000-4-30 Ed3 Class A Certificate
IEC61850 Communication Protocol
2nd ~ 31rd Harmonics Measurement
Disturbance Waveform Recording
2000+ Waveform Recording
5000+ SOE Recording
+86-18702106858 / +86-21-69156352
The Acrel APView500 is a high-precision power quality monitoring device designed to meet the IEC61000-4-30 standard. It offers comprehensive monitoring capabilities, including 2nd~63rd harmonic measurement, waveform sampling, voltage unbalance monitoring, flicker monitoring, and measurement control. The device supports IEC61850 communication protocol, ensuring seamless integration into modern power systems. With its advanced features and high accuracy, the APView500 is ideal for industries such as chemical, steel, metallurgy, hospitals, data centers, transportation, and construction, providing reliable data for power quality analysis and improvement.
| Technical Parameter | Value |
| Rated Value | AC voltage:AC/DC220V, AC/DC110V or DC48V |
| AC current:AC1A,5A; | |
| Overload capacity | 1.2In, continuous working |
| 20 times for 1 second | |
| power supply | Rated: AC/DC220, AC/DC110V or DC48V |
| Permissible deviation: -20%-+20% | |
| Power consumption:≤15W | |
| Power Consumption | ≤0.5VA (single phase) |
| Measuring rage | 0-1.2In |
| Digital output | Mechanical service life: ≥10000 |
| Output mode: Passive contacts | |
| Switching capacity: ≤4000W or ≤384VA | |
| On-state current: ≥16A(AC250V/DC24V) in the continuous mode; | |
| ≥30A for a short term (200ms) | |
| Accuracy | Class 0.5 |
| RMS Voltage：±0.1% | |
| RMS Current：±0.1% | |
| P,Q,S：±0.2% | |
| Power factor：Class 0.5 | |
| Voltage deviation：0.1% | |
| Frequency deviation：±0.001Hz | |
| Communication | RS485,Modbus-RTU protocol;Ethernet. |
| Three-phase unbalance | Voltage unbalance:±0.15% |
| Current unbalance:±1% | |
| Power frequency withstand voltage | Between power supply set of terminals and signal input, output set of terminals 2kV/1min (RMS) |
| Between the shell and all set of terminals(except the set of terminals reference voltage less than 40V) AC 4kV | |
| Temperature | Operation: -10℃～+55℃Storage: -30℃-+80℃ |
| Humidity | ≤95%RH, no condensation ,without corrosive gas |
| Altitude | ≤ 2500m |
