Multi-Circuits Measurement
Equipped with 3-in-1 CTs
Rated Current: 5A/100A/400A/600A
4G/WiFi/Ethernet/LoRa/LoRaWAN Comm.
Max. 4 Channels Three Phase or 12 Channels Single Phase
CE Certificated
RS485 Communication
Application: Apartment, Factory Production Line, School
+86-18702106858 / +86-21-69156352
Acrel ADW210 Multi Circuits Energy Meter is a highly versatile and advanced meter designed for efficient energy monitoring. It can support Wireless Communication (eg. 4G/WiFi/Ethernet/LoRa/LoRaWAN) by external module.
Equipped with 3 - in - 1 CTs, it supports multiple rated currents including 5A, 100A, 400A, and 600A, enabling flexible application in various scenarios and easily installed.
It can measure up to 4 channels of three - phase circuits or 12 channels of single - phase circuits simultaneously. With RS485 communication based on the Modbus - RTU protocol, it ensures reliable data transmission.
The device is CE certificated, guaranteeing safety and quality. It is widely applicable in apartments, factory production lines, schools, and other settings, providing precise and comprehensive energy monitoring. Its powerful functions and reliable performance make it an excellent choice for energy management.
| Auxiliary Power | AC/DC 85～265V or DC 40-60V; power consumption≤10VA; | ||
| Input Signal | Frequency | 45～65Hz; | |
| Voltage | Rated value: AC 3×220V/380V; | ||
| Overload: 1.2 times rated value (continuous); 2 times rated value/1 second; | |||
| power consumption: ≤ 0.5VA（each channel）; | |||
| Current | Rated value: Secondary input rated current：50mA | ||
| Overload: 1.2 times rated value (continuous); 10 times rated value/1 second; | |||
| power consumption: ≤ 0.5VA（each channel）; | |||
| Measurement Accuracy | Frequency: 0.05Hz, voltage and current: 0.5 class, active energy: 1 class, reactive energy: 2 class; 2nd to 31st harmonic accuracy: ±1%; | ||
| Function | Pulse output | Output method: optocoupler pulse with open collector,the pulse constant defaults to 400imp/kWh (and active open input can only be either-or.); | |
| communication | RS485 interface, Modbus-RTU protocol; baud rate 1200～38400; | ||
| Switch | Input | 2-way or 4-way passive dry contact input, built-in power supply; | |
| 2-way active wet node input (AC220V), identify the oil generator and mains access (and pulse output can only be either-or.); | |||
| Output | Output method: relay normally open contact output; | ||
| Contact rating: AC 250V/3A DC 30V/3A； | |||
